What is a steel platform and how do I design it?

In today's society, land is becoming more and more precious and scarce, so how to place as many goods as possible in a limited space is a problem that many businesses consider. Well, we can see that with the development of the times, the use of steel has become very common, and steel-based structures are one of the most important types of building structures, and steel structures with their own characteristics, will be more and more favored by enterprises. Now let xinmiao storage rack take you to know the steel platform used by many enterprises!

Steel platform, that is, the work platform, it is generally made of steel engineering structure, usually made of steel sections and steel plates, such as beams, columns, plates and other components, the platform is usually composed of paving slabs, primary and secondary beams, columns, columns between the support, as well as ladders, railings, etc.; between the components with welding, screws or rivets, etc. for connection, that is, belong to the fully assembled structure, the design is also more flexible.

Xinmiao steel platform features

So for the steel platform, what are its characteristics of this itself? Now is the Xinmiao steel platform for example, to show the specific introduction of steel platform! The characteristics of Xinmiao steel platform are as follows.

1. Steel platform that has a fully assembled structure.

2. For the steel platform, is still very flexible in design.

3. Steel platform has the ability to be designed and manufactured to meet the site characteristics according to different site conditions.

4. The functional requirements of the use of a steel platforms greatly meet the logistics requirements.

5. Steel platform is more widely used in modern storage characteristics.

6. The locking device between the plate and the floor is locked, the floor is flat, the integrity is strong, the load-bearing capacity is strong and uniform, and the cost is low.

Design requirements of xinmiao steel platform.

1. In the design of the platform structure, must determine the plane size of the platform structure, elevation, beam grid and column network arrangement in addition to meeting the requirements of use, beam, and column arrangement should also consider the location of the equipment load and other large concentrated loads on the platform as well as the hanging of large diameter industrial pipelines.

2. The design of the steel platform must meet the requirements of the process production operation and ensure the clearance for passage and operation.

3. In the design of the steel platform, the general net height of passage should not be less than 1.8M.

4. On the steel platform the platform should generally be set around the protective railing, the height of the railing is generally 1M.

5. When the platform height is greater than 2M, should be set under the protective railing height should be 100-150MM skirting board.

6. Platform should be set for the up and down passage of the ladder, the width of the ladder should not be less than 600MM.

7. Platform structure should strive to achieve economic and reasonable, direct and clear force transmission. The arrangement of the beam lattice should be adapted to its span. When the span of the beam is larger, its spacing should also be increased. Make full use of the allowable span of the paving slab and arrange the beam lattice reasonably to get a better economic effect.

What favorable conditions can xinmiao steel platform create for enterprises?

One, the steel used in the steel platform itself has its own characteristics of high strength, lightweight and high stiffness, which is mostly used in the construction of large spans and super high and super heavy buildings.

Second, for the material of steel structure, has good homogeneity and isotropy, and is considered to be an ideal elastomer, which is more in line with the basic assumptions of general engineering mechanics, and is the ideal building material today.

Third, the material of steel platform has good plasticity and toughness, and can have large deformation, so it can well withstand the dynamic load.

Fourth, for the steel platform, its construction period is short, generally speaking a three hundred square meters of construction, only five people, thirty working days can be, it can be done from construction to decoration in just one month. It can be said to save cost, save time and save labor.

Fifth, the high degree of industrialization of steel construction, and high degree of line mechanization, can be specialized production, improve efficiency and reduce the difficulty of construction. It is very compatible with the high speed and energy-saving society at this stage.

Daily work, how do we go to maintain xinmiao steel platform?

1, When using the steel platform, be sure to set the load limit sign.

2, In xinmiao steel platform shelving point and the upper tie point must be located on the building, and must not be set on scaffolding and other construction facilities, the support system must not be connected with scaffolding.

3, The concrete beam plate of the steel platform shelving point should be buried and connected with the bolts of the platform.

4, The horizontal angle between the steel wire rope and the platform shall be suitable for 45 degrees to 60 degrees.

5, The beam-column of the upper tie point of the steel platform shall be tested for tensile strength to ensure the safety of the building and the platform.

6, Steel platform should use the card ring, shall not make the hook directly hooked platform hanging ring.

7, Steel platform installation, steel wire rope should use special hook to hang firmly, take other ways when the snap shall not be less than 3, building sharp angle mouth around the wire rope should be lined with soft cushion, steel platform outside the mouth should be slightly higher than the inside.

8, Steel platform must be set up on the left and right sides of the fixed protection railing and hung with dense safety net.

Relatively speaking, the steel mezzanine still plays an important role in our daily life, and the steel structure is mainly used for the load-bearing skeleton of the heavy workshop, the structure of the plant subject to dynamic load, the plate and shell structure, the towering TV tower and mast structure, the bridge and library and other large-span structures, high-rise and super high-rise buildings, and also widely used in the automobile, electronics, machinery, storage and other industries.
